JBE-301Q 3MP POE Turret Camera product image

JBE-01Q / Selected Configuration: JBE-301Q

JBE-301Q 3MP Turret Camera

Compact 3MP POE turret camera for wired surveillance projects in offices, retail stores, warehouses and commercial buildings.

  • 3MP video
  • Single-cable POE installation
  • H.265 video compression
  • 3.6mm fixed lens
  • ONVIF for compatible NVR / VMS
  • Dual-light night vision
Ask About OEM Customization

Technical data

Technical specifications

Final values must be confirmed according to the selected model, app solution and project configuration.

Camera

Image SensorCMOS Sensor
Resolution3MP
Lens3.6mm fixed lens
ProtectionIP66

Video

CompressionH.264 / H.265

Network

EthernetWired Ethernet
POESupported
ONVIFSupported for compatible NVR / VMS platforms
Web / VMS / Mobile AppSupported

Night Vision

IR LEDs8 pcs
White LEDsDual-light LEDs

Audio

Built-in MicOptional
SpeakerOptional

General / Packaging

HousingPlastic
Housing Size1.5"
Box Size130*130*115mm
App OptionTSEYE

Configurations

Available Configurations

ModelResolutionLensAudioNetwork / POEAction
JBE-301QJBE-301Q 3MP POE Turret Camera3MP3.6mmOptionalYesCurrent Configuration
JBE-501QJBE-501Q 5MP POE Turret Camera5MP3.6mmOptionalYesView Configuration
JBE-501Q-2JBE-501Q-2 5MP POE Turret Camera5MP3.6mmOptionalYesView Configuration
JBE-801QJBE-801Q 8MP POE Turret Camera8MP / 4K3.6mmOptionalYesView Configuration
View all POE Cameras

PoE Camera Installation and Connections

All ports show functional connections only, not the rear-panel positions of any specific model. Check the selected camera, recorder, switch and power specifications before installation.

1. Direct Connection to a PoE NVR

  1. Connect each compatible PoE camera to a camera PoE port on the PoE NVR using an Ethernet cable.
  2. Connect the NVR LAN port to the router or local network. Connect a local monitor to the NVR HDMI output.
  3. Connect the specified NVR power supply. Check the PoE standard, per-port power and total power budget for the selected cameras.
  4. Configure and verify local recording. Internet access and the supported remote-access setup are required for viewing from outside the local network.

2. Connection via a PoE Switch

  1. Connect compatible PoE cameras to the PoE switch. A non-PoE IP camera needs its own specified power supply and an Ethernet data connection to the LAN.
  2. Connect the switch uplink to the router or LAN and connect the NVR LAN port to that same network. Follow the selected equipment documentation for the network topology.
  3. Power the NVR and PoE switch separately using their specified supplies. Connect the NVR HDMI output to a local monitor.
  4. Add compatible cameras to the NVR and verify recording. Confirm addressing, supported protocols, recording channels and the PoE power budget before installation.

Local recording and viewing on the connected monitor do not require internet. Remote viewing requires internet access and a supported, correctly configured remote-access method.

Direct Connection to a PoE NVR

Functional diagram: PoE cameras connect to NVR PoE ports; NVR LAN connects to a router, HDMI to a local monitor, and a separate supply powers the NVR.

Functional connections only; port positions are illustrative.
